LK 106MT Automatic Foil Stamping And Die Cutting Machine

Technical parameter:
Max. sheet size___________________________1060×770mm
Min. sheet size____________________________450×370mm
Max.die cutting size________________________1050×750mm
Max.stamping size_________________________1050×750mm
Inner chase size___________________________1100×790mm
Gripper margin___________________________8-17mm
Cutting accuracy__________________________±0.1mm
Paper range______________90-2000g/m2(cardboard); 0.1-2mm(cardboard);≤4mm(corrugated)
Max. working pressure______________________300T
Max. mechanical speed_____________________7500s/h
Max. stamping speed_______________________6500s/h
Press 1 foil pulling shafts____________________Longitudinal 3,transversal 2
Press 2 foil pulling shafts____________________Transversal 2
Press 1 Zones individually heated______________12 heating zones
Press 2 Zones individually heated______________12 heating zones
Max. foil diameter________________________¢250mm
Max. delivery pile height____________________1250mm
Max. feeding pile height____________________1350mm
Main motor power________________________30kw
Heating pipe power_______________________48kw
Servo motor power________________________24kw
Total Machine power______________________105kw
Air requirement__________________________40T
Machine weight__________________________40T
Overall machine dimension__________________9645×4145×2610mm





LK 2-106MT Automatic Foil Stamping and Die Cutting Machine

Technical parameter:
Max. sheet size(mm)____________1060×770
Min. sheet size(mm)____________450×370
Max. die cutting size(mm)________1050×750
Max. stamping size(mm)_________1050×750
Gripper Margin(mm)___________8-17
Paper range__________________90-2000gsm(cardboard)
__________________________0.1-2mm(cardboard)
__________________________≤4mm(corrugated)
Max. working pressure(T)_________300
Max. working speed(s/h)__________6500
Max. stamping speed(s/h)_________6000
Foil feeding shaft_______________7 (3 in longitudinal, 4 in transversal)
Zones individually heated_________24 (max to 200ºC)
Max. foil longitudinal diameter(mm)__250
Max. delivery pile height__________1200
Max. feeding pile height___________1350
Main motor power(KW)___________30
Power rating(KW)_______________89
Machine weight(kg)______________36800
Overall machine dimensions(mm)_______9600×4200×2260
Air requirements_____________________0.6Mpa, >0.37m³/min



LK 2 106MT automatic hot foil stamping and die cutting machine in one pass

LK 106MTF automatic hot foil stamping and die cutting machine in one pass
